120-160KW DC Fast Charging Station
Delivering rapid EV charging for commercial hubs, our DC fast charger ensures ultra-efficient power transfer. CE-certified for safety and performance, it supports multi-vehicle compatibility and dynamic load balancing. Ideal for highways, fleet depots, and public stations.
It supports RFID, 4G, Bluetooth, and WiFi connectivity. With OCPP 1.6J and our SaaS platform, you can manage your charging infrastructure effectively with 24/7 fault diagnostics. We also provide PV-ESS-EV Charging Station Solutions to maximize profits for our clients.
| Parameter Item | Specifications |
|---|---|
| Implementation Standards | GBT / CCS2 |
| Total Power | 120-160kW |
| Voltage Regulation Accuracy | ≤0.5% |
| Power Factor | ≥0.99 |
| AC Input Voltage | 380V(-25%,+25%) AC |
| Output Voltage Range | 50V~1000VDC |
| IP Protection Rating | IP54 |
| Appearance Size | 750(W) x 650(D) x 1700(H) mm |
| Protection Function | Overloading, Short Circuit, Overvoltage, Undervoltage, Insulation Detection, Lightning Protection |
