IP67 1500V Connector Solar Wire Waterproof Solar Connector Male and Female for 4/6mm2 PV Solar Cable

1 / 5

IP67 1500V Connector Solar Wire Waterproof Solar Connector Male and Female for 4/6mm2 PV Solar Cable

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Basic Specifications

Model NO.

LQ-2

Current

30A

Material

Copper

Flame Class

UL94-Hb/UL-94-V0

Cable Size

2.5mm2, 4mm2, 6mm2

Contact Resistance

0.5mΩ

Locking System

Snap-in Nur/Only Mc4

Ambient Temp

-40 ℃ to +90℃ IEC

Protection Degree

IP67 Mated

Gender

Female

Pins

3 Pins

Application

Power

Interface Type

DC/DC

Packing

100PCS/Bag

Origin

China

HS Code

8536900000

Product Description

Solar Panel Connectors (1000V)

The LQ-1 series is designed to connect electrical wiring using advanced MC techniques. These connecting cables are specifically suitable for the combination of solar panel connections. This product has been certified by TUV, ensuring high quality and reliability for PV systems.

Maximum Current	30A
Maximum Voltage	1500V
Operating Humidity	5% - 95% (No condensation)
Temperature Range	-40 ºC ~ +90 ºC
Waterproof Grade	IP67
Cable Specifications	4mm2
Test Voltage	6.6KV (50Hz, 1min)
Metal Materials	Nickel copper
Insulation Material	PA12 * 1988HB

Key Features:

The shell features strong anti-aging and anti-UV capabilities, making it ideal for harsh outdoor environments.
Designed to meet various needs and can be used in conjunction with a variety of cell junction boxes.
Secure self-locking mode and press-fit connection for all contact points.
Security Level: Class II.

Frequently Asked Questions

Q1: What is the waterproof rating of these solar connectors? A1: The connectors are rated IP67, providing excellent protection against dust and water immersion, suitable for outdoor solar installations.

Q2: What cable sizes can be used with this model? A2: These connectors are compatible with standard PV cable sizes including 2.5mm2, 4mm2, and 6mm2.

Q3: Are these connectors UV resistant? A3: Yes, the shell is made of materials with high anti-aging and anti-UV capabilities, specifically designed for long-term outdoor use in harsh environments.

Q4: What is the maximum voltage and current capacity? A4: The connectors support a maximum current of 30A and a maximum operating voltage of 1500V.

Q5: What material is used for the contact terminals? A5: The contact materials are made of high-quality copper with nickel plating to ensure minimal contact resistance (0.5mΩ).

Q6: What temperature range can these connectors withstand? A6: They are designed to operate reliably in an ambient temperature range of -40 ºC to +90 ºC.
