Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation
Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation
Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation
Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation
Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation
1 / 5
Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation
Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation
Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation
Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation
Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation

Air Conditioner Disconnect Switch Adapted for PV DC System Safety Isolation

Customization: Available
Type: DC Isolator Switch
Structure: Double-column Disconnector
Send Inquiry

Product Description

Basic Information & Specification
Model NO.
CYGL-40
Installation
DIN Rail / Panel Mount
Operation
Manual
Number of Poles
4 Poles
IP Level
66
Max. Current
25A
Max. Voltage
1200V
Certification
ISO, CE
Warranty
1 Year
Package Size
53.00cm * 30.00cm * 33.50cm
Product Description
PV DC System Safety Isolation

The PV Photovoltaic DC Switch is a high-performance disconnect switch specifically designed for solar power systems. Engineered to safely interrupt direct current (DC) in photovoltaic applications, this switch ensures reliable isolation of the solar array during maintenance, installation, or emergency shutdowns.

Built with advanced arc-extinguishing technology, the switch offers excellent performance under high-voltage and high-current DC conditions. Housed in a durable, weatherproof enclosure with IP65 protection rating, this DC switch is ideal for both indoor and outdoor installations.

🛡️ Reliable Arc Suppression
Advanced arc-extinguishing technology ensures safe operation under load.
☀️ UV & Flame Retardant
Built with durable materials suitable for harsh environmental conditions.
🔧 Easy Installation
Compact design with clear polarity marking and user-friendly terminals.
📜 Standard Compliance
Meets international standards such as IEC 60947-3, AS 60947.3, and CE certified.
Product Parameters
ParameterSpecification
Rated Voltage500VDC / 600VDC / 1000VDC / 1200VDC / 1500VDC
Rated Current16A / 20A / 25A / 32A / 40A / 63A / 100A
Poles2P / 4P / 6P
Protection DegreeIP65 / IP66 / IP67
Mechanical Life≥ 20,000 operations
Ambient Temperature-25°C to +70°C
StandardIEC 60947-3 / AS 60947.3
Detailed Photos
Detail 1
Detail 2
Detail 3
Detail 4
Detail 5
Detail 6
Packaging & Shipping
To ensure the safe delivery of your Isolation Switch, we use high-quality wooden crates for packaging. Each unit is securely packed to prevent damage during transit and handling.
Packaging 1
Packaging 2
Manufacturing Capability
We are a leading manufacturer and exporter specializing in high-quality electrical equipment. Our global presence provides advanced solutions for power transmission, distribution, and management. All products are designed to meet international standards of quality, safety, and efficiency.
Factory 1
Factory 2
Factory 3
Certificates
Frequently Asked Questions
1. What is a PV DC Switch?
A PV DC switch (Photovoltaic Direct Current switch) is a disconnect device designed specifically for solar power systems to safely connect or disconnect the DC current generated by solar panels.
2. Why is a DC switch necessary in a solar system?
DC current is difficult to interrupt. This switch handles high voltage and continuous DC, enabling safe disconnection during maintenance and preventing fire hazards.
3. What voltage and current ratings are available?
Common ratings include 600V, 1000V, 1200V, and 1500V DC, with current capacities typically ranging from 16A to 100A.
4. Does it have polarity requirements?
Yes, most PV DC switches are polarity-sensitive. Wiring must strictly follow the positive (+) and negative (−) terminals indicated on the device.
5. Can it be installed outdoors?
Yes, our switches feature protection ratings of IP65 or higher, making them resistant to water and dust for outdoor environments.
6. What are the packaging standards?
Each switch is packed in sturdy, export-grade wooden crates to prevent damage during sea and air freight.
